Model: YN27C
The host weight: 27kg Drilling depth: ≥6M
Iron idling speed: >200r/min
Iron shank size bit rod: 22x108mm
YN27C type internal combustion rock drill is widely used in mining, road construction, quarrying, national defense engineering, etc., with various functions of splitting, crushing, tamping and chipping for mining, cement road surface and asphalt road surface.
YN27C internal combustion rock drill has the functions of drilling, splitting, crushing, ramming, shoveling and so on. It can drill holesin rock vertically down, horizontally down to less than 45° and vertically down to the deepest 6 meters. YN27C is widely used in mining, road construction, quarrying, national defense engineering, etc.
| model | YN27C | Deepest drilling depth | >6M |
| The host weight | 27 kg | Fuel tank capacity | ≥1.14L |
| Carburetor type | No float type | The borehole speed | ≥250MM/MIN |
| engine type | gasoline engine | Ratio | 12° 1 |
| sparking mode | SR contactless system | Spark plug electrodega | 0.5-0.7MM |
| engine capacity | 185cm3 | Oil consumption rate | <0.12L/M |
| Legal and load speed | ≥2450r/min | Striking energy | >25J |
| Iron idling speed | >200r/min | The borehole diameter | 26-46 (MM) |
| Iron shank size bit rod | 22x108mm | Iron shank size bit rod Hexagon | 22 x108mm |
Notice: There is a chance that SHANDIKE may make changes on above-mentioned information. Product pictures and parameters about models, data, performances and specifications on this website are for reference only.
