Tricone Drill Bits-Steel teeth

Steel teeth series:IADC CODE:116,117,126,127,136,137,216,217,317,337

TCI series:IADC CODE:417,437,447,517,527,537,547,617,627,637,647,737,837.

Application: it can be used for geological prospecting, development of oil and gas, drilling water wells,blast holes and making holes for seismic prospecting,construction engineering.

You can also send us a message and we will reply to you within 24 hours.

Email: sales@sdkdrillingtools.com Get Latest Price

Product Details

Parameters

Product Details

Our Steel Teeth Tricone Drill Bits are engineered for exceptional performance in soft to medium-hard formations. Designed for oil and gas exploration, water well drilling, geothermal projects, and mining operations, these robust drill bits combine advanced design with premium materials to deliver unmatched durability and drilling efficiency.

Key Features

1. Premium Steel Teeth Construction

Forged from high-grade alloy steel, the teeth are heat-treated for superior hardness and wear resistance, ensuring extended service life even in abrasive conditions.

Optimized tooth geometry enhances cutting efficiency and reduces balling in sticky formations.

2. Interchangeable Bearings & Seals

Equipped with sealed and lubricated roller bearings, our tricone bits minimize friction and heat buildup, prolonging bearing life.

Modular design allows for easy maintenance and replacement of worn components.

3. Versatile Formation Compatibility

Ideal for soft to medium-hard formations such as shale, limestone, sandstone, and unconsolidated sediments.

Available in multiple sizes (6″ to 26″) and IADC codes to match specific drilling requirements.

4. Enhanced Hydraulics

Strategically placed nozzles and fluid channels optimize cuttings removal, improving ROP (Rate of Penetration) and reducing downtime.

Advantages Over Competitors

Cost-Effective: Steel teeth provide a lower initial cost compared to TCI (Tungsten Carbide Insert) bits, ideal for budget-conscious projects.

Easy Maintenance: Simplified refurbishment process reduces operational costs.

Proven Reliability: Rigorous QA testing ensures consistent performance in challenging environments.

Applications

Oil & gas well drilling

Water well construction

Geotechnical and environmental sampling

Mining and blast hole drilling

Technical Specifications

Material: High-strength alloy steel body with hardened steel teeth

Bearing Type: Sealed roller bearings (optional journal bearings available)

Connection Types: API regular, API numbered, or custom threads

IADC Code: 1-1-1 to 5-5-5 (depending on configuration)

Quality Assurance

Every tricone drill bit undergoes stringent inspections, including pressure testing, dimensional checks, and dynamic balance verification, to meet ISO 9001 and API standards.

Why Choose Us?

Customization: Tailor-made designs for unique drilling challenges.

Global Support: 24/7 technical assistance and rapid logistics.

Proven Track Record: Trusted by drilling contractors worldwide for over [X] years.

Contact Us Today to discuss your project needs and discover how our Steel Teeth Tricone Drill Bits can optimize your drilling performance while reducing costs!

Parameters

IADC	WOB	RPM	Application
IADC	(KN/mm)	(r/min)	Application
111/114/115	0.3-0.75	200-80	very soft formations with low compressive strength and high drill ability, like clay, mudstone, chalk
116/117	0.35-0.8	150-80	very soft formations with low compressive strength and high drill ability, like clay, mudstone, chalk
121	0.3-0.85	200-80	soft formations with low compressive strength and high drill ability, like mudstone, gypsum, salt, soft limestone
124/125		180-60
131	0.3-0.95	180-80	soft to medium formations with low compressive strength, like medium, soft shake, medium soft limestone, medium soft sandstone, medium formation with harder and abrasive interbeds
136/137	0.35-1.0	120-60
211/241	0.3-0.95	180-80	medium formations with high compressive strength, like medium, soft shake, hard gypsum, medium soft limestone, medium soft sandstone, soft formation with harder interbeds.
216/217	0.4-1.0	100-60
246/247	0.4-1.0	80-50	medium hard formation with high compressive strength, like hard shale, limestone, sandstone, dolomite
321	0.4-1.0	150-70	medium abrasive formations, like abrasive shale, limestone, sandstone, dolomite, hard gypsum, marble
324	0.4-1.0	120-50
437/447/435	0.35-0.9	240-70	very soft formations with low compressive strength and high drill ability, like clay, mudstone, chalk, gypsum, salt, soft limestone
517/527/515	0.35-1.0	220-60	soft formations with low compressive strength and high drill ability, like mudstone, gypsum, salt, soft limestone
537/547/535	0.45-1.0	220-50	soft to medium formations with low compressive strength, like medium, soft shake, medium soft limestone, medium soft sandstone, medium formation with harder and abrasive interbeds
617/615	0.45-1.1	200-50	medium hard formation with high compressive strength, like hard shale, limestone, sandstone, dolomite
637/635	0.5-1.1	180-40	hard formation with high compressive strength, like limestone, sandstone, dolomite, hard gypsum, marble
Note: Above limits of WOB and RRPM should not be used simultaneously

Diameter		Steel tooth bit	TCI bit
in	mm	Weight(kgs)	Weight(kgs)
3 7/8	98.4	5	6
4 5/8	117.5	6	6.5
5 7/8	149.2	17	18
6	152.4	18	19.5
6 1/2	165.1	19	22
7 7/8	200	29	29.5
8 1/2	215.9	35	38
8 3/4	222.2	36	40
9 1/2	241.3	57	59
9 7/8	250.8	58	60
10 5/8	269.9	66	74
12 1/4	311.1	85	111
13 5/8	346.1	118	120
14 3/4	374.6	140	160
17 1/2	444.5	230	255
20	508	428	443
22	558.8	520	560
26	660.4	720	810

Notice: There is a chance that SHANDIKE may make changes on above-mentioned information. Product pictures and parameters about models, data, performances and specifications on this website are for reference only.
